Description
3,2 TON
- Replaces 2903701 and 2903711 ( picture as reference)
- Lowering Speed Control
- PU Wheels give easy and silent movement and protects the the workshop floor.
- Unique Magic Lift design offers Super fast lifting speed with only 1 stroke to the lifting point.
- Rubber lift pad prevents any scratching of vehicle chassis.
- Soft foam handle protection prevents accidental damage to the vehicle’s bodywork.
- Air vent valve plug automatically eliminates air in the hydraulic unit.
- Overload protection protects the jack to overload its limit.
- Universal Joint System gives longer life than the traditional gear type system on most jacks.
- Designed for every day heavy duty use.
TECHNICAL SPECIFICATIONS
Capacity: 3200 Kg
Min height: 130 mm
Max height: 548 mm
Weight: 39,8 kg
See Drawing above
A: 130 mm
B: 548 mm
C: 418 mm
E: 1320 mm
F: 125 mm
I: 85 mm
J: 40 mm
L: 758 mm
W: 351 mm
H: 165 mm
DOWNLOADS :
Download the latest manual and spareparts overview
